Windows 10 64-bit requirements: Does my CPU support CMPXCHG16b, PrefetchW and LAHF/SAHF?

I'm currently trying to find out whether or not it would be a good idea to update my slightly dated notebook (Windows 7, 64-bit) to Windows 10. The problem is that Microsoft states in their Windows 10 specifications that to use the 64-bit version of Windows 10, a processor which supports CMPXCHG16b, PrefetchW and LAHF/SAHF is needed. I know that my processor is 64-bit (Intel Core i5-2430M @ 2.40 GHz) but I don't know how to find out whether it supports CMPXCHG16b, PrefetchW and LAHF/SAHF, and I have no idea what these mean.

I tried using Google and got no results that made sense to me, only some comparison of my i5 and a similar AMD processor. I also checked Intel's ARK website. If somebody could point me to where I can get more info I would be really grateful.

4 Answers

Your processor supports these features. In fact, the same features are required to run 64-bit Windows 8.1. This requirement is met by all modern processors and is generally only an issue with certain Core 2 and earlier processors.

What are these instructions?

• The CMPXCHG16B instruction performs an atomic compare-and-exchange on 16-byte values. It is supported on all modern x86-64 processors, although some early AMD64 CPUs did not support it. This instruction may also be referred to as CompareExchange128. See also: How prevalent are old x64 processors lacking the cmpxchg16b instruction?

• Early AMD64 processors lacked the CMPXCHG16B instruction, which is an extension of the CMPXCHG8B instruction present on most post-80486 processors. Similar to CMPXCHG8B, CMPXCHG16B allows for atomic operations on octal words. This is useful for parallel algorithms that use compare and swap on data larger than the size of a pointer, common in lock-free and wait-free algorithms. Without CMPXCHG16B one must use workarounds, such as a critical section or alternative lock-free approaches. Its absence also prevents 64-bit Windows prior to Windows 8.1 from having a user-mode address space larger than 8 terabytes. The 64-bit version of Windows 8.1 requires the instruction.

• The PREFETCHW instruction is a hint to the processor to prefetch data from memory into the cache in anticipation for writing (Intel Instruction Set Reference, PDF page 888). This instruction was introduced in AMD's 3DNow! instruction set, which is deprecated except for the PREFETCH and PREFETCHW instructions. All AMD processors since the Athlon 64 support this instruction. However, this instruction may not be supported in some older 64-bit Intel processors predating Nehalem.

• The LAHF and SAHF load and store the contents of the AH register into the flags register, respectively (Intel Instruction Set Reference, PDF pages 530 and 1025). Some older Intel processors without hardware virtualization (VT-x) functionality do not support this instruction when running in 64-bit long mode; these are mostly limited to certain low-end processors predating Nehalem. Some very old AMD64 processors also lack this feature.

• Early AMD64 and Intel 64 CPUs lacked LAHF and SAHF instructions in 64-bit mode. AMD introduced these instructions (also in 64-bit mode) with their Athlon 64, Opteron and Turion 64 revision D processors in March 2005 while Intel introduced the instructions with the Pentium 4 G1 stepping in December 2005. The 64-bit version of Windows 8.1 requires this feature.

What does this mean for me?

• All Intel Core i7, i5, or i3 processors, as well as all Pentium or Celeron processors based on the Clarkdale, Arrandale, Sandy Bridge, or newer microarchitectures, support these features, as well as Intel Atom and Celeron Silvermont processors. For AMD, all but the oldest 64-bit processors have these features.

• You generally only need to be concerned about these instructions if you have a processor that predates the above. The Get Windows 10 app will tell you if you can upgrade to Windows 10. If the processor doesn't meet requirements, you'll get "The CPU isn't supported."

If you can use the command line in Windows then:

• Get SysInternals coreinfo.exe from technet
• Run coreinfo > coreinfo.txt
• Open the file in a text editor, and do a find (case insensitive) for each of the instructions

PS: In Linux you would use grep flags /proc/cpuinfo | head -1

There is a utility called coreinfo, provided by Microsoft, that provides functionality like cat /proc/cpuinfo on Linux.

You have to search through this but you can find the information here,

LAHF-SAHF - Supports LAHF/SAHF instructions in 64-bit mode NX - Supports no-execute page protection CX16 * Supports CMPXCHG16B instruction X64 * Supports 64-bit mode PREFETCHW - Supports PREFETCHW instruction

The - mean that the CPU lacks that feature, the * mean it has that feature.

Now that I look, coreinfo is actually suggested by Microsoft to make the determination on that doc page,

Coreinfo is a tool you can use to confirm which of these capabilities your CPU has.+

Full result for my processor, a Intel E7525, looks like this,

Coreinfo v3.31 - Dump information on system CPU and memory topology Copyright (C) 2008-2014 Mark Russinovich Sysinternals - Intel(R) Xeon(TM) CPU 3.40GHz x86 Family 15 Model 4 Stepping 3, GenuineIntel Microcode signature: 00000005 HTT * Hyperthreading enabled HYPERVISOR - Hypervisor is present VMX - Supports Intel hardware-assisted virtualization SVM - Supports AMD hardware-assisted virtualization X64 * Supports 64-bit mode SMX - Supports Intel trusted execution SKINIT - Supports AMD SKINIT NX - Supports no-execute page protection SMEP - Supports Supervisor Mode Execution Prevention SMAP - Supports Supervisor Mode Access Prevention PAGE1GB - Supports 1 GB large pages PAE * Supports > 32-bit physical addresses PAT * Supports Page Attribute Table PSE * Supports 4 MB pages PSE36 * Supports > 32-bit address 4 MB pages PGE * Supports global bit in page tables SS * Supports bus snooping for cache operations VME * Supports Virtual-8086 mode RDWRFSGSBASE - Supports direct GS/FS base access FPU * Implements i387 floating point instructions MMX * Supports MMX instruction set MMXEXT - Implements AMD MMX extensions 3DNOW - Supports 3DNow! instructions 3DNOWEXT - Supports 3DNow! extension instructions SSE * Supports Streaming SIMD Extensions SSE2 * Supports Streaming SIMD Extensions 2 SSE3 * Supports Streaming SIMD Extensions 3 SSSE3 - Supports Supplemental SIMD Extensions 3 SSE4a - Supports Streaming SIMDR Extensions 4a SSE4.1 - Supports Streaming SIMD Extensions 4.1 SSE4.2 - Supports Streaming SIMD Extensions 4.2 AES - Supports AES extensions AVX - Supports AVX intruction extensions FMA - Supports FMA extensions using YMM state MSR * Implements RDMSR/WRMSR instructions MTRR * Supports Memory Type Range Registers XSAVE - Supports XSAVE/XRSTOR instructions OSXSAVE - Supports XSETBV/XGETBV instructions RDRAND - Supports RDRAND instruction RDSEED - Supports RDSEED instruction CMOV * Supports CMOVcc instruction CLFSH * Supports CLFLUSH instruction CX8 * Supports compare and exchange 8-byte instructions CX16 * Supports CMPXCHG16B instruction BMI1 - Supports bit manipulation extensions 1 BMI2 - Supports bit manipulation extensions 2 ADX - Supports ADCX/ADOX instructions DCA - Supports prefetch from memory-mapped device F16C - Supports half-precision instruction FXSR * Supports FXSAVE/FXSTOR instructions FFXSR - Supports optimized FXSAVE/FSRSTOR instruction MONITOR * Supports MONITOR and MWAIT instructions MOVBE - Supports MOVBE instruction ERMSB - Supports Enhanced REP MOVSB/STOSB PCLMULDQ - Supports PCLMULDQ instruction POPCNT - Supports POPCNT instruction LZCNT - Supports LZCNT instruction SEP * Supports fast system call instructions LAHF-SAHF - Supports LAHF/SAHF instructions in 64-bit mode HLE - Supports Hardware Lock Elision instructions RTM - Supports Restricted Transactional Memory instructions DE * Supports I/O breakpoints including CR4.DE DTES64 * Can write history of 64-bit branch addresses DS * Implements memory-resident debug buffer DS-CPL * Supports Debug Store feature with CPL PCID - Supports PCIDs and settable CR4.PCIDE INVPCID - Supports INVPCID instruction PDCM - Supports Performance Capabilities MSR RDTSCP - Supports RDTSCP instruction TSC * Supports RDTSC instruction TSC-DEADLINE - Local APIC supports one-shot deadline timer TSC-INVARIANT - TSC runs at constant rate xTPR * Supports disabling task priority messages EIST * Supports Enhanced Intel Speedstep ACPI * Implements MSR for power management TM * Implements thermal monitor circuitry TM2 - Implements Thermal Monitor 2 control APIC * Implements software-accessible local APIC x2APIC - Supports x2APIC CNXT-ID * L1 data cache mode adaptive or BIOS MCE * Supports Machine Check, INT18 and CR4.MCE MCA * Implements Machine Check Architecture PBE * Supports use of FERR#/PBE# pin PSN - Implements 96-bit processor serial number PREFETCHW - Supports PREFETCHW instruction Maximum implemented CPUID leaves: 00000005 (Basic), 80000008 (Extended). Logical to Physical Processor Map: *- Physical Processor 0 -* Physical Processor 1 Logical Processor to Socket Map: Logical Processor to NUMA Node Map: ** NUMA Node 0 Logical Processor to Cache Map:

"Intel(R) Core(TM) i7-2600K CPU @ 3.40GHz"

"PREFETCHWT1 Instruction Not Supported"

From AIDA 64 Extreme. ^^

These three - CMPXCHG16b, PrefetchW and LAHF/SAHF are required for upgrade to a 64bit version of Windows 10 from a current 64bit installation of Windows 7.
